Crane Sunlift Major Electric (175 Kg.)

Crane Sunlift Major Electric (175 Kg.)

Capacity up to 175 kg. Transfer crane and electric patient lift, with a capacity of up to 175 kg.

Sending, please wait...

Your question has been sent! We'll answer you as soon as possible.

Sorry! An error has occurred sending your question.

Crane Sunlift Major Electric (175 Kg.)

€834.55
Tax included Delivery: 1 to 2 weeks (Europe)
Capacity up to 175 kg. Transfer crane and electric patient lift, with a capacity of up to 175 kg.

Sunlift Major has a great capacity of elevation and resistance, reason why it is especially indicated for residences and hospitals. It is also very easy to handle.

175 Kg maximum lifting weight
Lifting capacity up to 1,813 mm
Minimum height of the hanger 575 mm

Maximum security

Hangers covered with non-slip material and with hooks that cross to prevent the strap of the harness from coming loose. This crane has a battery level indicator and an acoustic warning against total discharge when the manual control is pressed.

Maximum stiffness

The models of Sunlift cranes are characterized by their exceptional rigidity. This is possible thanks to the special design of all its anchor points, which has allowed to eliminate any type of slack.

Very easy to handle

Wide ergonomic handle that allows to position the elbows at 90º for a more comfortable handling of the crane from different positions without forcing the wrist. Coated by a layer of paint very pleasant to the touch, easy to clean and hygienic.

Leg opening

The legs are opened and closed pressing the ergonomic pedal with the foot to get a greater or less width of the crane.



Technical specifications (common in all 4 models)

Batteries: 2 x 12vacid gel Battery capacity: 2.9 Amph Charger input current: 230 v / 50 Hz 0.12 A Charger output current: 28 v 0.5 Amph


SUNLIFT Micro SUNLIFT Mini
Patient maximum weight 130 kg 130 kg
Maximum total length
(with wheels out)
1.110 mm 1.130 mm
Minimum total length
(with wheels inwards)
970 mm 1.065 mm
Max width with closed legs 545 mm 540 mm
Maximum total height (without load) (A) 1.725 mm 1,870 mm
Minimum total height (no load) (B) 1.130 mm 1.280 mm
Maximum height of the hanger (without load) (C) 1,483 mm 1,628 mm
Minimum height of the hanger (without load) 460 mm 513 mm
Turning radius with open legs (D) 1.130 mm 1.240 mm

Open legs: (E)
Maximum width (external)
Maximum width (internal)

870 mm
740 mm
940 mm
810 mm
Closed legs: (F)
Maximum width (external)
Maximum width (internal)
545 mm
465 mm
540 mm
470 mm
Height at the upper edge of the legs 100 mm 100 mm
Minimum free height above ground 20 mm 20 mm
Front wheels 75 mm 75 mm
Rear wheels 100 mm 100 mm
Weight set mast, arm and electronic components 16.6 kg 17,54 kg
Joint weight of the base 13.34 kg 13.6 kg
Weight of batteries 2.76 kg 2.76 kg

SUNLIFT Midi SUNLIFT Major
Patient maximum weight 150 kg 1375 kg
Maximum total length
(with wheels out)
1.225 mm 1,340 mm
Minimum total length
(with wheels inwards)
1,160 mm 1.275 mm
Max width with closed legs 640 mm 650 mm
Maximum total height (without load) (A) 1,940 mm 2006 mm
Minimum total height (no load) (B) 1,285 mm 1.435 mm
Maximum height of the hanger (without load) (C) 1,688 mm 1.813 mm
Minimum height of the hanger (without load) 555 mm 575 mm
Turning radius with open legs (D) 1.380 mm 1,500 mm

Open legs: (E)
Maximum width (external)
Maximum width (internal)

1.075 mm
980 mm
1,185 mm
1,105 mm
Closed legs: (F)
Maximum width (external)
Maximum width (internal)
640 mm
540 mm
650 mm
520 mm
Height at the upper edge of the legs 100 mm 110 mm
Minimum free height above ground 20 mm 15 mm
Front wheels 75 mm 75 mm
Rear wheels 100 mm 100 mm
Weight set mast, arm and electronic components 17.6 kg 22.75 kg
Joint weight of the base 14.10 kg 18.1 kg
Weight of batteries 2.76 kg 2.76 kg
Sunlift Major
New product
No reviews
